Armadillo® A2 & A3

Innovative. Versatile. Speedy. Rugged.

 Aluminum Hard-Shell Side-Open Options:

Sleeping Dimensions (scroll down for full specs)
Armadillo A2: 56″ (W) x 78″ (L)
Armadillo A3: 72″ (W) x 86″ (L)
  • Rugged 14 GA Fully Welded Aluminum Hard-Shell uniquely styled and aerodynamic with semi-textured high-gloss black finish is trail-hardened and ready to deflect low-hanging branches or high-speed roadways in all conditions –  rain or shine!
  • 23ZERO’s One-of-Kind Light Suppression Technology® (LST®) Fabric is a leading-edge combination of a UV treatment, and an advanced Polyurethane coating that stays up to 15% cooler and ensures darkness (almost zero light penetration) until you open the windows to start your day. Sleep better than ever before in a roof-top tent. Control the light – control your comfort!
  • 2” Rebound Foam Quilted Mattress wrapped in a breathable quilted poly topper in olive. The newly engineered mattress has a higher latex content to resume its original shape much faster than traditional high-density foam roof-top tent mattresses. It feels firmer even though on paper it has the same specs as its predecessor.
  •  Right & Left Side-Open Deployment allows an optimized placement on your choice of Overland Rigs ranging from smaller crossovers and wagons, to bed mounted mid-sized 4×4’s, to monster custom builds. In light of all international vehicle options

$3,795.00$3,995.00

-

Description





Rugged 14 GA Fully Welded Aluminum Hard-Shell uniquely styled and aerodynamic with semi-textured high-gloss black finish is trail-hardened and ready to deflect low hanging branches or high-speed roadways in all conditions – rain or shine!

Light Suppression Technology® (LST®) is a leading-edge combination of a UV treatment, and an advanced Polyurethane coating that stays up to 15% cooler and ensures darkness (almost zero light penetration) until you open the windows to start your day. Sleep better than ever before in a roof-top tent. Early summer sunrise, being bathed in light, sweating, and squinting through the odd canvas-colored tints are a thing of the past! Control the light – control your comfort!

2” Rebound Foam Mattress wrapped in a breathable quilted poly topper in olive. The newly engineered mattress has a higher latex content to resume its original shape much faster than traditional high-density foam roof-top tent mattresses. It feels firmer even though on paper it has the same specs as its predecessor. Side-sleepers will not slowly sink to the bottom and be left in valleys and troughs if you are prone to toss and turn all night. A water-resistant, breathable, removable, and quilted topper in 23ZERO Olive Green ensures comfort while matching the internal quilted head-liner

Right & Left Side-Open Deployment allows an optimized placement on your choice of Overland Rigs ranging from smaller crossovers and wagons, to bed mounted mid-sized 4×4’s, to monster custom builds. In light of all international vehicle options, 23ZERO defines left and right based on the drivers left and right as they sit oriented behind the steering wheel, or related to your turn signals. The Armadillo A has a clear front and back and is not styled or designed to be mounted backwards or sideways. However, we respect you and Bon Jovi is saying “It’s My Life”!



Key Features

Armadillo A2 Armadillo A3
Open Direction Options Right and Left Right and Left
Opening/Closing Method -2 x Internal heavy duty gas struts
-3 x Heavy duty 100mm stainless steel hinges opening to nearly 90°
-Built-in 4-point elastic shock cord bands for tent pack-up assistance
-Mid-body closing-side handle
-11” x 1 ½” [22” in total] Nylon lid pull strap
-2 x Internal heavy duty gas struts
-3 x Heavy duty 100mm stainless steel hinges opening to nearly 90°
-Built-in 4-point elastic shock cord bands for tent pack-up assistance
-Mid-body closing-side handle
-11” x 1 ½” [22” in total] Nylon lid pull strap
Latch -2 x Adjustable Heavy Duty over-center safety 4001-toggle Latches with Lock-Ready Hole
-2 x 1’ Nylon Hook & Loop Webbing and Rectangle D-Ring
-2 x Adjustable Heavy Duty over-center safety 4001-toggle Latches with Lock-Ready Hole
-2 x 1’ Nylon Hook & Loop Webbing and Rectangle D-Ring
Number of Entrances -1 x 33” Over ladder entrance
-Outer 40” x 30” Side-zipping rigid-roll-and-stow LST fabric door
-Inner 33” U-zip insect mesh closure with pvc toggle and loop fasteners
-Full entrance-width rainfly canopy secured by 2 x covered no-leak blind-rivit spring poles
-2 x 37” Black-tipped cold-rolled steel spring poles
-1 x 33” Over ladder entrance
-Outer 43” x 33” Side-zipping rigid-roll-and-stow LST fabric door
-Inner 40” x 33″” U-zip insect mesh closure with pvc toggle and loop fasteners
-Full entrance-width rainfly canopy secured by 2 x covered no-leak blind-rivit spring poles
-2 x 37” Black-tipped cold-rolled steel spring poles
Number of Window(s) -2 x 48” x 30” outer N-zip insect mesh closures with pvc toggle and loop fasteners and Inner N-zip LST windows capped by 2 x Extendable or roll-and-stowed LST arched weather canopies, 4 x 33” Red-tipped cold-rolled steel spring poles seated in tent frame and locked into ¾” stainless steel reinforced blind rivets extending the window canopies.
-1 x 30” Roof vent positioned under rainfly with an outer U-zip insect mesh closures with pvc toggle and loop fasteners and Inner U-zip LST flap
-2 x 48” x 30” outer N-zip insect mesh closures with pvc toggle and loop fasteners and Inner N-zip LST windows capped by 2 x Extendable or roll-and-stowed LST arched weather canopies, 4 x 33” Red-tipped cold-rolled steel spring poles seated in tent frame and locked into ¾” stainless steel reinforced blind rivets extending the window canopies.
-1 x 30” Roof vent positioned under rainfly with an outer U-zip insect mesh closures with pvc toggle and loop fasteners and Inner U-zip LST flap
Internal Storage Dimensions – 56” (L) x 18” (W) X 12” (H) – Measured from hinge side out 18” (Opposite of Entrance) – 72” (L) x 18” (W) X 12” (H) – Measured from hinge side out 18” (Opposite of Entrance)
Included Accessories -1 x Portable 24” 5V USB LED aluminum clip-on pole light with built-in dimmer that mounts to any ¾” pole internal & external paired with 2 x internal hanging portable power supply pouches [Power supply NOT included]
-2 x Removable sail-track gear bags in olive – 1 x mesh-pockets style & (1) gusseted footwear style
-1 x Adjustable internal aluminum snow/peak pole for more tension & support
-2 x Internal storage pouch
-1 x Tent mounting kit
-1 x Portable 24” 5V USB LED aluminum clip-on pole light with built-in dimmer that mounts to any ¾” pole internal & external paired with 2 x internal hanging portable power supply pouches [Power supply NOT included]
-2 x Removable sail-track gear bags in olive – 1 x mesh-pockets style & (1) gusseted footwear style
-1 x Adjustable internal aluminum snow/peak pole for more tension & support
-2 x Internal storage pouch
-1 x Tent mounting kit
-1 x 35” x 22” Removable sail-track gear Ladder-Guard with 1 x mesh-pockets in Olive

Sleeping

Armadillo A2 Armadillo A3
Sleeping Capacity 2 Adults Comfortably 3 Adults Comfortably
Weight Capacity 440 lbs. 660 lbs.
Sleeping Footprint 56” (W) x 78 (L) – Sleeping space and mattress transition from 56” down to 54” to accommodate hinge. Equal to ±Full XL Mattress 72” (W) x 86″” (L) with a bonus 12″” of head/foot room in the hinge-side contor of the hard-shell. Mattress transitions from 72” down to 70” to accommodate hinges. Equal to ± Cali-King Mattress
Mattress 2” Rebound Foam with removable quilted nylon topper in olive 2” Rebound Foam with removable quilted nylon topper in olive
Peak internal height 44” increased with adjustable internal snow/peak pole 49” increased with adjustable internal snow/peak pole
Open Internal Dimensions 56” (W) x 78” (L) x 44” (H) [W = side to side L = Front to back H = Base to peak] 72” (W) x 86” (L) x 49” (H) [W = side to side L = Front to back H = Base to peak]
Lighting 1 x Portable 24” 5V USB LED aluminum clip-on pole light with built-in dimmer that mounts to any ¾” pole internal & external paired with 2 x internal hanging portable power supply pouches [Power supply NOT included] 1 x Portable 24” 5V USB LED aluminum clip-on pole light with built-in dimmer that mounts to any ¾” pole internal & external paired with 2 x internal hanging portable power supply pouches [Power supply NOT included]
3 or 4 Season Tent? 4 4

Vehicle Mounting

Armadillo A2 Armadillo A3
Tent Weight 195 lbs 204 lbs
Recommended Racks: Rack Rated for 190 Dynamic lbs Rack Rated for 190 Dynamic lbs
Closed Outside Dimensions 49″” (W) x 62″” (L) x 14″” (H)
W = side to side
L = Front to back
56″” (W) x 78″” (L) x 14″” (H)
W = side to side
L = Front to back
Open Outside Dimension 56 (W) x 88 (L) x 48 (H)

W = side to side

L = Front to back

78 “”(W) x 98″” (L) x 54″” (H)

W = side to side

L = Front to back

Mounting Rails ( Base) 1” Square 3 side T-Slot rails

60” (L) Front to back

28” on Center between rails

11” from the edge

1” Square 3 side T-Slot rails

73” (L) Front to back

30.5” on Center between rails

12.75” from the edge

Top Accessory Mounting Rails T-slot

Extruded Aluminum

31” long

35” Center to center between rails

T-slot

Extruded Aluminum

45.3/4” long

35 3/8” Center to center between rails

Accessories Rails Weight Capacity Yes – 60 lbs. Yes – 60 lbs.
Mounting Kit Includes: 6 Window Poles with bag
4 Mounting Plates
8 Bolts
8 Nylock Nut
13mm ratching & box wrench
2 Guy lines
2 Stakes
4 Rail End-caps
1 Side Open handle & hareware
6 Window Poles with bag
4 Mounting Plates
8 Bolts
8 Nylock Nut
13mm ratching & box wrench
2 Guy lines
2 Stakes
4 Rail End-caps
1 Side Open handle & hareware

Construction

Armadillo A2 Armadillo A3
Tent Color Olive Green Olive Green
Outer Shell Color semi-textured high-gloss black finish semi-textured high-gloss black finish
Outer Shell Material 14 GA Fully Welded Aluminum Hard-Shell 14 GA Fully Welded Aluminum Hard-Shell
Tent Baseboard Material
Base Tent Fabric 280 GSM RipStop Poly-Cotton canvas with LST 280 GSM RipStop Poly-Cotton canvas with LST
Rainfly Fabric PU Polyester PU Polyester
Insect Mesh Material
Internal Frame Material
Ceiling material Green Quilted Nylon Green Quilted Nylon
Mattress Cover Green Quilted Nylon Topper Green Quilted Nylon Topper
Ladder Yes Yes
Add-Ons
Annex Availability Yes – Available 2023 Yes – Available 2023

Additional information

CHOOSE FROM: A2: 49" (W) x 62" (L) x 14" (H) - OR - A3: 56" (W) x 78" (L) x 14" (H)

ARMADILLO A2, ARMADILLO A3

OPENS:

LEFT, RIGHT
